cMT3090

$997.00

HMI with 9.7″ XGA TFT Display and Built-in Server

with CODESYS

The cMT3090 offers a bright 1024 x 768 pixel 9.7″ touchscreen display, built-in mono speaker, fast 1 GHz processor, and 1 GB of RAM for graphics-intensive projects. This model comes with built-in EasyAccess 2.0, OPC UA, and MQTT support, as well as a built-in HMI server enabling remote monitoring and access to HMIs via an Apple or Android tablet or smart phone

Weight 10 lbs
Dimensions 16 × 12 × 8 in

Features

  • 9.7″ 1024 x 768 TFT LCD
  • Fan-less Cooling System
  • Built- in 4GB Flash Memory and RTC
  • SD Card Slot Supports SD/SDHC Cards
  • COM2 / COM3 RS-485 2W Supports MPI 187.5K
  • CAN Bus Supports CANopen Protocol
  • NEMA4/IP65 Compliant Front Panel
  • Built-in EasyAccess 2.0 License
