The cMT3072XHT(L) offers a high bright 11024 x 600 pixel 7.0″ touchscreen WVA display, fast Quad-core CPU with High Performance Dedicated 3D Processor, 1 GB of RAM for graphics-intensive projects and extended temperature range. The cMT3072XHT(L) has optional EasyAccess 2.0 for remote monitoring and access to HMIs via an Apple or Android tablet or smart phone.
cMT Series Advanced
cMT3072XHT(L)
$799.00
HMI with 7” High Brightness HMI, High Resolution, IPS Screen, Extended Temperature Range
| Weight | 5 lbs |
|---|---|
| Dimensions | 12 × 10 × 6 in |
Features
-
7″ 1024 x 600 Wide Viewing Angle LCD, LED Backlight
-
High Brightness LCD Display
-
Quad-core CPU with High Performance Dedicated 3D Processor
-
Fan-less Cooling System
-
Built- in 4GB Flash Memory and RTC
-
COM2 and COM3 RS-485 2W supports MPI 187.5K, please use one at a time
-
CAN Bus Supports CANopen, CAN Bus 2.0A/2.0B and SAE J1939
-
Built-in Power Isolator
-
NEMA4 / IP66 Compliant Front Panel
-
The aluminum enclosure performs stably in harsh environment
-
The operating temperature can be as low as -20°C
