cMT3108XP

$1,199.00

Smart Capacitive HMI with 10.1″ 1280×800 WVA LCD Display, LED Backlight

with CODESYS

ThecMT3108XP features a capacitive touch screen that supports multi-touch gesture features, similar to what we are all used to on our phones, which can be used to reduce the number of on-screen buttons needed, thereby simplifying project screen layout. Furthermore, cMT3108XP incorporates a thin-bezel design that increases screen space by 10%, while the 1280 x 800 high resolution display with 89ยฐ all-around wide viewing angle delivers exceptional viewing experience.

Weight 5 lbs
Dimensions 12 × 10 × 6 in

Features



  • 10.1″ 1280 x 800 Wide Viewing AngleLCD, LED Backlight
  • Built-in 4GB Flash Memory and RTC
  • COM2 and COM3RS-4852W support MPI 187.5K, please use one at atime.
  • CAN Bus Supports CANopen, CAN Bus 2.0A/2.0B and SAE J1939
  • Fan-less Cooling System
  • PCB coating process ensureshigh reliability toresist from corrosionin harsh environment.
  • Built-in Power Isolation
  • NEMA4/IP66Compliant Front Panel
  • Compatible with M02 WiFi ExpansionModule that supports wireless communication.
